THERMISTOR RESISTANCE AND TEMPERATURE CHARACTERISTICS
74
TEMP TEMP
Thermistor
Resistance
Volts
Thermistor
Resistance
Volts
(°C)
(F) R k DC V) R k DC V)
-30 -22 364.43 4.58 4759.15 4.96
-25 -13 267.00 4.45 3454.24 4.94
-20 -4 197.81 4.29 2533.62 4.92
-15 5 148.10 4.09 1877.01 4.90
-10 14 111.99 3.86 1403.82 4.86
-5 23 85.49 3.61 1059.45 4.82
0 32 65.84 3.33 806.47 4.77
5 41 51.09 3.04 618.95 4.70
10 50 39.96 2.74 478.76 4.62
15 59 31.50 2.44 373.11 4.53
20 68 25.01 2.16 292.86 4.41
25 77 20.00 1.89 231.44 4.28
30 86 16.10 1.64 184.11 4.13
35 95 13.04 1.42 147.37 3.95
40 104 10.63 1.22 118.68 3.76
45 113 8.71 1.04 96.13 3.56
50 122 7.18 0.89 78.29 3.34
55 131 5.95 0.76 64.10 3.11
60 140 4.96 0.65 52.76 2.87
65 149 4.16 0.56 43.63 2.64
70 158 3.50 0.48 36.26 2.41
75 167 2.96 0.41 30.27 2.18
80 176 2.51 0.35 25.38 1.97
85 185 2.14 0.30 21.37 1.77
90 194 1.83 0.26 18.06 1.58
95 203 1.58 0.23 15.33 1.41
100 212 1.36 0.20 13.06 1.25
105 221 1.18 0.17 11.17 1.11
110 230 1.02 0.15 9.59 0.99
115 239 0.89 0.13 8.25 0.87
120 248 0.78 0.12 7.13 0.77
125 257 0.68 0.10 6.18 0.68
130 266 0.60 0.09 5.37 0.61
135 275 0.53 0.08 4.69 0.54
140 284 0.47 0.07 4.10 0.48
145 293 0.42 0.06 3.59 0.42
150 302 0.37 0.
06 3.16 0.37
Td : Discharge
Tm : Coil
Tl : Liquid
Tgi: Indoor Gas
Tli: Indoor Liquid
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
8.73 1.05
7.18 0.89
13.07 1.42
10.65 1.22
20.04 1.89
16.13 1.64
31.54 2.44
25.06 2.16
51.10 3.04
39.99 2.74
85.43 3.61
65.80 3.33
147.86 4.09
111.88 3.86
197.31 4.28
R k DC V)
362.48 4.58
Ta : Ambient
Thermistor
Resistance
Volts
265.99 4.45
