7 SEGMENT DISPLAY-OUTDOOR UNIT
65
SCREEN 0 (Display FAULT CODE)
Setting
No.
setoNstnetnoC
1 Fault code (present)
SCREEN 1 (Display FAULT CODES)
Setting
No.
setoNstnetnoC
tsetaL)tsetal( edoc tluaF1
dn2)dn2( edoc tluaF2
dr3)dr3( edoc tluaF3
ht4)ht4( edoc tluaF4
ht5)ht5( edoc tluaF5
ht6)ht6( edoc tluaF6
SCREEN 2 (MONITOR MODE)
Setting
No.
setoNstnetnoC
1 Compressor operation time unit
：
hr (Multiply by 200,)
2 Operation code
0: Stop
1. Cooling Start-up
3. Oil Return Operation
6: Cooling Operation
3 Compr
essor Reduction Mode 0:OFF,1:ON
4 % demand
unit
：
%
(Cut off the decimal first place.)
5 act % demand
unit
：
%
(Cut off the decimal first place.)
6 Requested ID CFM unit
：
CFM (Multiply by 10)
7 Reported ID CFM unit
：
CFM (Multiply by 10)
8 Outdoor FAN RPM unit
：
RPM (Multiply by 10)
9 Ta (Outdoor Air Temperature) unit
：
F
10 Td (Discharge Temperature) unit
：
F
11 Tm (Outdoor Coil Temperature) unit
：
F
13 Tl (Liquid Temperature) unit
：
F
14 Pressure Sensor unit
：
PSI
