6 x Parameter settings
Daikin RoCon
Daikin Control unit
008.1543999_00 – 03/2017 – EN
Operating instructions
45
6.4 Rotary switch setting: Operating Mode
6.5 Rotary switch setting: Set Temp Day
6.6 Rotary switch setting: Set Temp Night
6.7 Rotary switch setting: DHW Set Temp
Parameter Description Access Setting range
Min / Max
Factory
setting
Incre-
ment
BE HF
Standby In this operating mode all internal functions are switched off. Frost protection remains active and
a blocking protection for the pump is guaranteed.
All controllers integrated in the RoCon system via the CAN bus are primarily also switched to the
operating mode if this setting is selected.
Outputs are not always completely free of voltage.
E E -
Reducing The internal heating circuit is continuously controlled (24 h per day) to the set setback tempera-
ture. Hot water generation is carried out according to [DHW Program 1].
E E -
Heating The internal heating circuit is continuously controlled (24 h per day) to the set day room target
temperature (heating). Hot water generation is carried out according to [DHW Program 1].
E E -
Summer The internal heating circuit is switched off. Frost protection remains active and a blocking protec-
tion for the pump is guaranteed. Hot water generation is carried out according to [DHW Program
1].
All controllers integrated in the RoCon system via the CAN bus are primarily also switched to the
operating mode if this setting is selected.
E E -
Automatic 1 The internal heating circuits are controlled according to the set [HC Program 1] time program with
the respective room target temperatures. Hot water generation is carried out according to [DHW
Program 1].
E E -
Automatic 2 The internal heating circuits are controlled according to the set [HC Program 2] time program with
the respective room target temperatures. Hot water generation is carried out according to [DHW
Program 2].
E E -
Tab. 6-8 Parameters in the "Operating Mode" rotary switch setting
Parameter Description Access Setting range
Min / Max
Factory
setting
Incre-
ment
BE HF
T-Room 1 Setpoint Target value of the room temperature in °C, which is valid for the 1st switching time cycle of the
[Automatic 1] and [Automatic 2] time programs.
E E 5 - 40 °C 20 °C 0.5 °C
T-Room 2 Setpoint Target value of the room temperature in °C, which is valid for the 2nd switching time cycle of the
[Automatic 1] and [Automatic 2] time programs.
E E 5 - 40 °C 20 °C 0.5 °C
T-Room 3 Setpoint Target value of the room temperature in °C, which is valid for the 3rd switching time cycle of the
[Automatic 1] and [Automatic 2] time programs.
E E 5 - 40 °C 20 °C 0.5 °C
Tab. 6-9 Parameters in the "Set Temp Day" rotary switch setting
Parameter Description Access Setting range
Min / Max
Factory
setting
Incre-
ment
BE HF
T-Reduced Target value of the setback room temperature in °C, which is valid for the [Automatic 1] and [Au-
tomatic 2] time programs.
E E 5 - 40 °C 10 °C 0.5 °C
T-Absence Target value of the setback room temperature in °C, which is valid for the [Away] + [Vacation]
time programs.
E E 5 - 40 °C 15 °C 0.5 °C
Tab. 6-10 Parameters in the "Set Temp Night" rotary switch setting
Parameter Description Access Setting range
Min / Max
Factory
setting
Incre-
ment
BE HF
T-DHW Setpoint 1 Target value of the hot water temperature in °C, which is valid for the 1st switching time cycle of
the [Automatic 1] and [Automatic 2] time programs.
E E 10 - 70 °C 58 °C 1 °C
T-DHW Setpoint 2 Target value of the hot water temperature in °C, which is valid for the 2nd switching time cycle
of the [Automatic 1] and [Automatic 2] time programs.
E E 10 - 70 °C 58 °C 1 °C
T-DHW Setpoint 3 Target value of the hot water temperature in °C, which is valid for the 3rd switching time cycle of
the [Automatic 1] and [Automatic 2] time programs.
E E 10 - 70 °C 58 °C 1 °C
Tab. 6-11 Parameters in the "DHW Set Temp" rotary switch setting
