7 | Unit installation
Installer reference guide
79
ERGA04~08EA + EHVH04+08SU18+23EA
Daikin Altherma 3 R F
4P629090-1A – 2021.11
a Maximum snowfall height
b EKFT008D option kit
c Anti-vibration rubber (field supply)
7.3.4 To install the outdoor unit
CAUTION
Do NOT remove the protective cardboard before the unit is installed properly.
1 Lift the outdoor unit as described in "4.2.2To handle the outdoor unit"[423].
2 Install the outdoor unit as follows:
