10. FIELD SETTINGS
CAUTION
Beforecarryingouteldsetting,checktheitemsmentionedin
1. Items to be checked after the installation work is
completed on page 3.
• Check if all the installation and piping works for the air
conditioner are completed.
• Check that the outside panel and piping cover of the indoor
and outdoor units are closed.
< FIELD SETTINGS >
Afterturningonthepowersupply,carryouteldsetting
from the remote controller according to the installation
state.
• Carry out setting at 3 places, “Mode No.”, “FIRST CODE No.”
and “SECOND CODE No.”.
The settings shown by
in the following tables indicate
those when shipped from the factory.
• The method of setting procedure and operation is shown in
the installation manual attached to the remote controller.
NOTE
• Though setting of “Mode No.” is carried out as a group, if
you intend to carry out individual setting by each indoor
unit or confirmation after setting, carry out setting with the
Mode No. shown in the parenthesis().
• Ask the user to keep the manual attached to the remote
controller together with the operation manual.
• Do not carry out settings other than those shown in the table.
• Settings are performed by selecting “Mode No.”, “FIRST
CODE No.”, and “SECOND CODE No.”.
10-1 SETTINGS FOR EXTERNAL STATIC PRESSURE
• Make settings in either method (a) or method (b).
(a) Make settings with Air volume automatic adjustment
function.
“Air volume automatic adjustment” function: The air volume
is adjusted to the rated air volume automatically.
CAUTION
• Be sure to check that the external static pressure is within
thespecicationrangebeforemakingsettings.Theexternal
static pressure will not be automatically adjusted and air
volumeinsufciencyorwaterleakagemayresultifthe
external static pressure is outside the range. (Refer to the
technical document for the setting range of external static
pressure.)
(1) Check that the electrical wiring and duct work have been
completed.
(If the closing damper is set midway, be sure to check that
the damper is opened. Furthermore, check that the air
passageonthesuctionsideisprovidedwithanairlter
(eldsupply)).
(2) If air conditioner has more than one air outlet and air inlet,
be sure to make adjustments so that the air volume ratio of
each air outlet and the corresponding air inlet will conform
to the designed air volume ratio.
In that case, set the operating mode to “Fan”. (In the case
of changing the air volume, press the fan speed button on
the remote controller and change the current selection to
“High”, “Medium”, or “Low”.)
(3) Make settings to adjust the air volume automatically.
After setting the operating mode to “Fan”, set the air
conditionertoeldsettingmodewiththeoperationofthe
air conditioner stopped. Select Mode No. [21] (11 in the
case of batch settings), select FIRST CODE No. “7”, and
set the SECOND CODE No. to “03”.
Return to the “Basic screen” (“Normal mode” if a wireless
remote controller is used), and press the ON/OFF button.
The operation lamp is lit, and the indoor unit will go into fan
operation for air volume automatic adjustments (at which
time, do not adjust the opening of the air outlet or inlet).
The air volume adjustments will automatically terminate
approximately 1 to 15 minutes after the indoor unit comes
into operation, and the operation lamp will be OFF and the
indoor unit will come to a stop.
Table 4
Mode
No.
FIRST
CODE
No.
Setting
content
SECOND CODE No.
01 02
03
11(21) 7
Air volume
adjustment
OFF
Air volume
adjustment
completion
Air volume
adjustment
start
CAUTION
• Ifairowpathwaychanges,suchasductandairoutlet
changes, are made after air volume adjustments, be sure to
make “Air volume automatic adjustment” again.
• Ifairowpathwaychanges,suchasductandairoutlet
changes, are made after 11. TRIAL OPERATION AND
TESTING or air conditioner relocation, contact your dealer.
