Read Before Operation
Air inlet
ON/OFF
Indoor Unit
Display
Front panel
Air outlet
Louvers (vertical blades)
• The louvers are inside of the air
outlet.
Page 14
Flaps (horizontal blades)
Page 14
Model name
Indoor temperature sensor
• Detects the air temperature around
the unit.
OPERATION lamp (green)
TIMER lamp (orange)
Page 17,18
Signal receiver
• Receives signals from the remote
controller.
• When the unit receives a signal, you
will hear a beep sound.
Case Sound type
Operation start beep-beep
Setting changed beep
Operation stop long beep
Indoor unit ON/OFF switch
• Press this switch once to start operation.
Press once again to stop it.
• For the operation mode setting, refer to the following table.
Mode Temperature setting Airow rate
AUTO 77°F (25°C) AUTO
• This switch can be used when the remote controller is missing.
Names of Parts
FTX15NMVJU / FTX18NMVJU / FTX24NMVJU / FTXN18NMVJU / FTXN24NMVJU
01_EN_3P379751-4C.indd 7 11/6/2015 16:14:30
