Read Before Operation
Outdoor Unit
• The appearance of the outdoor unit may differ between different models.
 Open the front panel
Refrigerant pipes and
inter-unit wire
Drain hose
Air outlet
Model name
Ground terminal (inside)
Air inlet
(back and side)
Outdoor temperature
sensor (back)
Titanium apatite
deodorizing fi lter
(with frame)*
*FTXN18/24NMVJU: Sold separately.
Air  lter
