Read Before Operation
Names of Parts
Remote Controller
Signal transmitter
Receiver
•
To use the remote controller, aim the
transmitter at the indoor unit. If there is
anything blocking the signals between
the unit and the remote controller, such
as a curtain, the unit may not operate.
•
The maximum transmission distance is
about 23ft (7m).
FAN setting button
• Selects the air ow rate setting.
Page 12
POWERFUL button
• POWERFUL operation.
Page 15
Model ARC466A21
Display (LCD)
• Displays the current settings.
(In this illustration, each section is
shown with all its displays on for the
purpose of explanation.)
TEMPERATURE
adjustment button
• Changes the temperature setting.
Page 11
ON/OFF button
• Press this button once to start
operation.
Press once again to stop it.
Page 11
Front cover
• Open the front cover.
Page 8
