Read Before Operation
 Open the front panel
Outdoor Unit
• The appearance of the outdoor unit may differ between different models.
Refrigerant pipes and
inter-unit wire
Ground terminal
(inside)
Drain hose
Air inlet
(back and side)
Air outlet
Outdoor temperature
sensor (back)
Model name
• How to open the front panel:
Page 28
Air outlet selection switch
Page 14
• This setting blows air from upper
outlet only.
• This setting automatically decides a
blow pattern depending on mode
and conditions. (Setting at time of
purchase)
• This setting is recommended.
Indoor temperature sensor
• Detects the air temperature around the unit.
Titanium apatite
deodorizing filter
Air filter
