5.3 Temperature Setting
Press or button for increase or decrease of setting temperature under on-state of the unit. If press either
of them continuously, temperature will be increased or decreased by 1°C every 0.5s.
In Cooling, Dry, Fan and Heating mode, temperature setting range is 16 ∼ 30°C.
In Auto mode, the setting temperature is un-adjustable.
As shown in Fig.5.3
5.3Fig.
5.4 Fan Speed Setting
Press Fan button, fan speed of indoor unit will change as below:
As shown in Fig.5.4
Auto Low Middle High
5.4Fig.
