Description of parts
Indoor unit
Outdoor unit
: Run
: Timer
Symbol shown on the display:
Air in
Air out
Remote controller
Air in
Air out
(1)
(2)
(8)
(9)
(3)
(4) (5)
(6)
(7)
(1) Power cable
(2) Remote controller
(3) Front panel
(4) Air filter
(5) Guide louver
(6) Wall pipe
(7) Bind tape
(8) Connection wire
(9) Drainage pipe
