Daikin FTK35BVMB - Removal of Partition Plate and Reactor

Outdoor Unit SiBE04-302
166 Removal Procedure
2.6 Removal of Partition Plate and Reactor
Procedure Warning Be sure to turn off all power supplies at least 10 min. before disassembling work.
Step Procedure Points
1. Remove the partition plate.
1
Remove the two
screws fixing the
partition plate.
2
Pull the partition plate
upward to remove.
