SiBE04-302 Specifications
Specifications 13
230V, 50Hz
Notes:

MAX. interunit piping length: 25m

MAX. interunit height difference: 15m

Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m

The data are based on the conditions shown in the table below.
Models
Indoor Units ATK25BVMB ATK35BVMB
Outdoor Units ARK25BVMB ARK35BVMB
Capacity
Rated (Min.~Max.)
kW 2.5 (1.3~3.0) 3.15 (1.4~3.8)
Btu/h 8,550 (4,450~10,250) 10,750 (4,800~13,000)
kcal/h 2,150 (1,120~2,580) 2,710 (1,200~3,270)
Moisture Removal L/h 1.2 1.7
Running Current (Rated) A 4.5 6.0
Power Consumption
Rated (Min.~Max.)
W 890 (430~1,250) 1,120 (500~1,720)
Power Factor % 86.0 81.2
COP (Rated) W/W 2.81 2.81
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit ATK25BVMB ATK35BVMB
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 7.8 (275) 8.0 (283)
M 6.0 (212) 6.3 (222)
L 4.2 (148) 4.5 (159)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps and Auto 5 Steps and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185
Packaged Dimensions (W×D×H) mm 834×325×258 834×325×258
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L dBA 39 / 33 / 26 39 / 33 / 27
Sound Power dBA H 55 55
Outdoor Unit ARK25BVMB ARK35BVMB
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23KXA#A 1YC23KXA#A
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.43 0.43
Refrigerant
Type R410A R410A
Charge kg 0.79 0.96
Air Flow Rate
m³/min 29.0 27.5
cfm 1,025 972
Fan
Type Propeller Propeller
Motor Output W 25 25
Running Current (Rated) A 4.32 5.82
Power Consumption (Rated) W 850 1,080
Power Factor % 85.5 80.7
Starting Current A 4.5 6.0
Dimensions (H×W×D) mm 560×695×265 560×695×265
Packaged Dimensions (W×D×H) mm 797×310×599 797×310×599
Weight kg 34 37
Gross Weight kg 37 40
Operation Sound dBA 46 47
Sound Power dBA H 59 60
Drawing No. 3D039749B 3D039750B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
