Daikin FTK35BVMB - Function and Control

Specifications SiBE04-302
20 Specifications
230V, 50Hz
Notes:

MAX. interunit piping length: 15m

MAX. interunit height difference: 15m

Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m

The data are based on the conditions shown in the table below.
Models
Indoor Units FTYS20BVMB FTYS25BVMB
Outdoor Units
RYS20BVMB RYS20BVMB
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.0 2.6 2.5 3.3
Btu/h 6,850 8,900 8,550 11,300
kcal/h 1,720 2,240 2,150 2,840
Moisture Removal L/h 0.9 — 1.2 —
Running Current (Rated) A 3.4 4.1 4.5 5.0
Power Consumption
Rated (Min.~Max.)
W 690 805 890 1,025
Power Factor % 88.2 85.4 86.0 89.1
COP (Rated) W/W 2.90 3.23 2.81 3.22
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FTYS20BVMB FTYS25BVMB
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 7.5 (265) 7.6 (265) 7.8 (276) 7.9 (279)
M 5.6 (198) 6.3 (223) 6.0 (212) 6.6 (233)
L 3.9 (138) 5.0 (177) 4.2 (148) 5.3 (187)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps and Auto 5 Steps and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185
Packaged Dimensions (W×D×H) mm 834×325×258 834×325×258
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L dBA 38 / 32 / 26 38 / 32 / 26 39 / 33 / 27 39 / 33 / 27
Sound Power dBA H 54 — 55 —
Outdoor Units RYS20BVMB RYS25BVMB
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23KXA#A 1YC23KXA#A
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.43 0.43
Refrigerant
Type R410A R410A
Charge kg 0.79 0.79
Air Flow Rate
m³/min 29.0 25.5 29.0 25.5
cfm 1,025 901 1,025 901
Fan
Type Propeller Propeller
Motor Output W 25 25
Running Current (Rated) A 3.22 3.92 4.32 4.82
Power Consumption (Rated) W 650 765 850 985
Power Factor % 87.8 84.8 85.5 88.9
Starting Current A 4.1 5.0
Dimensions (H×W×D) mm 560×695×265 560×695×265
Packaged Dimensions (W×D×H) mm 797×310×599 797×310×599
Weight kg 34 34
Gross Weight kg 37 37
Operation Sound dBA 47 48 47 48
Sound Power dBA H 60 — 60 —
Drawing No. 3D039746A 3D039747A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
