Daikin FTXG25CVMAW Service Manual

Si04-402A Specifications
Specifications 5
230V, 50Hz
Notes:

MAX. interunit piping length: 20m

MAX. interunit height difference: 15m

Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m

The data are based on the conditions shown in the table below.
Model
Indoor Units FTXG25CVMBW FTXG25CVMBS
Outdoor Units
RXG25CVMB RXG25CVMB
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.5 (1.3~3.0) 3.4 (1.3~4.5) 2.5 (1.3~3.0) 3.4 (1.3~4.5)
Btu/h 8,550 (4,450~10,250) 11,600 (4,450~15,350) 8,550 (4,450~10,250) 11,600 (4,450~15,350)
kcal/h 2,150 (1,120~2,580) 2,920 (1,120~3,870) 2,150 (1,120~2,580) 2,920 (1,120~3,870)
Moisture Removal L/h 1.2 — 1.2 —
Running Current (Rated) A 3.4 4.5 3.4 4.5
Power Consumption
Rated (Min.~Max.)
W 620 (300~950) 825 (290~1,420) 620 (300~950) 825 (290~1,420)
Power Factor % 79.3 79.7 79.3 79.7
COP W/W 4.03 4.12 4.03 4.12
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FTXG25CVMBW FTXG25CVMBS
Front Panel Color Mat Crystal White Mat Crystal Silver
Air Flow Rate
m³/min
(cfm)
H 7.4 (260) 7.7 (271) 7.4 (260) 7.7 (271)
M 6.0 (211) 6.9 (243) 6.0 (211) 6.9 (243)
L 4.4 (155) 6.0 (211) 4.4 (155) 6.0 (211)
SL 3.7 (130) 5.0 (176) 3.7 (130) 5.0 (176)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.14 0.14 0.14 0.14
Power Consumption (Rated) W 30 30 30 30
Power Factor % 93.2 93.2 93.2 93.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 275×840×150 275×840×150
Packaged Dimensions (H×W×D) mm 222×894×345 222×894×345
Weight kg 9 9
Gross Weight kg 13 13
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/33/28/25 38/32/25/22 38/33/28/25
Sound Power H dBA 56 — 56 —
Outdoor Unit RXG25CVMB RXG25CVMB
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD#A 1YC23NXD#A
Motor Output W 600 600
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Model R410A R410A
Charge kg 1.00 1.00
Air Flow Rate
(H/L)
m³/min 31.3/22.4 28.1/22.4 31.3/22.4 28.1/22.4
cfm 1,105/791 992/791 1,105/791 992/791
Fan
Type Propeller Propeller
Motor Output W 35 35
Running Current (Rated) A 3.26 4.36 3.26 4.36
Power Consumption (Rated) W 590 795 590 795
Power Factor % 78.7 79.3 78.7 79.3
Starting Current A 4.5 4.5
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 589×882×363 589×882×363
Weight kg 32 32
Gross Weight kg 38 38
Operation
Sound
H/L dBA 46/43 47/44 46/43 47/44
Sound Power H dBA 61 — 61 —
Drawing No. 3D045212 3D045213
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
