ESIE17-19C | Part 3. Repair 3.3. Unit specific repair procedures
19/08/19 | Version 1.1 Page 85
Optimized Heating 4
Figure 3-18: Removing the compressor
1. Screw 6. Nut
2. Partition plate assembly 7. Compressor
3. Terminal cover 8. Putty
4. Compressor wiring 9. Dampers
5. Compressor pipe 10. Bushing
1
2
1
3
8
7
4
5
5
8 9
3
3
8 9
