Printed Circuit Board Connector Wiring Diagram SiBE01-829
10 Printed Circuit Board Connector Wiring Diagram
1. Printed Circuit Board Connector Wiring Diagram
1.1 Indoor Unit
Connectors PCB(1)(Control PCB)
PCB(2)(Display PCB)
Note: Other designations
PCB(1)(Control PCB)
PCB(2)(Display PCB)
1) CN_FANFB,
CN_FAN
Connector for AC fan motor
2) CN_STP Connector for swing motor (horizontal blades)
3) CN_DISP Connector for display PCB
4) CN_ODCOIL Connector for outdoor thermistor
5) CN_TBTF Connector for terminal fuse
1) CN_MB Connector for control PCB
1) V1 Varistor
2) FUSE1 Fuse (3.15A)
1) S1W ON / OFF switch
2) H1P LED for operation (green)
3) H2P LED for timer (yellow)
