14 | Technical data
Installer reference guide
56
CVXM-A, FVXM-A, CVXM-A9, FVXM-A9, FVXTM-A
Split system air conditioners
4P625991-1F – 2022.09
14 Technical data
A subset of the latest technical data is available on the regional Daikin website
(publicly accessible).
The full set of latest technical data is available on the Daikin Business Portal
(authentication required).
14.1 Wiring diagram
Translation of wiring the diagram notes
On wiring diagram Translation
Caution: When the main power is
turned OFF and then back on again,
operation will resume automatically.
Caution: When the main power is
turned OFF and then back on again,
operation will resume automatically.
Notice: (*) Applicable for units with
refrigerant leakage sensor only.
Notice: (*) Applicable for units with
refrigerant leakage sensor only.
14.1.1 Unified wiring diagram legend
For applied parts and numbering, refer to the wiring diagram on the unit. Part
numbering is by Arabic numbers in ascending order for each part and is
represented in the overview below by "*" in the part code.
Symbol Meaning Symbol Meaning
Circuit breaker Protective earth
Connection Protective earth (screw)
,
Connector
A
,
Rectifier
Earth Relay connector
Field wiring Short-circuit connector
Fuse Terminal
INDOOR
Indoor unit Terminal strip
OUTDOOR
Outdoor unit Wire clamp
Residual current
device
Symbol Colour Symbol Colour
BLK Black ORG Orange
BLU Blue PNK Pink
BRN Brown PRP, PPL Purple
GRN Green RED Red
GRY Grey WHT White
