Daikin J-Series Engineeiring Data

Capacity Tables EDUS041016
12 Room Air Conditioners J-Series
7. Capacity Tables
7.1 Cooling Only
FTKN09JEVJU + RKN09JEVJU
(60Hz 208/230V)
3D066771
AFR 9.2
BF 0.23
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CDB)
EWB EDB 20.0 25.0 30.0 32.0 35.0 40.0
°C °C TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20.0 2.32 1.85 0.58 2.32 1.85 0.65 2.32 1.85 0.73 2.27 1.83 0.75 2.20 1.80 0.79 2.09 1.74 0.84
16.0 22.0 2.67 1.93 0.61 2.55 1.88 0.67 2.43 1.83 0.73 2.39 1.81 0.75 2.32 1.77 0.79 2.20 1.72 0.85
18.0 25.0 2.78 2.03 0.62 2.66 1.99 0.68 2.55 1.94 0.73 2.50 1.92 0.76 2.43 1.89 0.79 2.32 1.84 0.85
19.4 26.7 2.84 2.16 0.62 2.72 2.11 0.68 2.61 2.06 0.74 2.56 2.04 0.76
2.49 2.01 0.80 2.37 1.97 0.85
22.0 30.0 3.01 2.08 0.62 2.89 2.04 0.68 2.78 2.00 0.74 2.73 1.98 0.77 2.66 1.96 0.80 2.55 1.92 0.86
24.0 32.0 3.12 2.03 0.63 3.01 1.99 0.69 2.89 1.96 0.75 2.85 1.94 0.77 2.78 1.92 0.80 2.66 1.88 0.86
Temp: Fahrenheit / TC, SHC: kBtu / PI: kW
INDOOR OUTDOOR TEMPERATURE (°FDB)
EWB EDB 68.0 77.0 86.0 90.0 95.0 104.0
°F °F TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
57.2 68.0 7.92 5.43 0.58 7.92 5.43 0.65 7.92 5.43 0.73 7.76 5.30 0.75 7.52 5.11 0.79 7.13 4.80 0.79
60.8 71.6 9.10 6.05 0.61 8.70 5.71 0.67 8.31 5.39 0.73 8.15 5.27 0.75 7.91 5.08 0.79 7.52 4.79 0.80
64.4 77.0 9.49 6.09 0.62 9.10 5.78 0.68 8.70 5.47 0.73 8.54 5.35 0.76 8.30 5.17 0.79 7.91 4.89 0.80
67.0 80.0 9.69 6.18 0.62 9.29 5.86 0.68 8.90 5.56 0.74 8.74 5.45 0.76
8.50 5.27 0.80 8.10 5.00 0.80
71.6 86.0 10.27 5.93 0.62 9.88 5.64 0.68 9.48 5.36 0.74 9.32 5.26 0.77 9.09 5.10 0.80 8.69 4.84 0.81
75.289.610.675.720.6310.275.450.699.875.190.759.725.090.779.484.940.809.084.700.81
Symbols Note:
AFR : Airflow rate (m
3
/min.) 1. Ratings shown are net capacities which include a deduction for indoor fan
motor heat.
2. shows nominal (rated) capacities and power input.
3. TC, PI and SHC must be calculated by interpolation using the figures in
the above tables. (Figures out of the tables should not be used for
calculation.)
4. About SHC which are not mentioned on the table, please calculate them
with around values in direct proportion.
5. Capacities are based on the following conditions.
Corresponding refrigerant piping length : 25 ft
Level difference : 0 ft
6. Airflow rate (AFR) and Bypass factor (BF) are tabulated above table.
BF : Bypass factor
EWB : Entering wet bulb temp. (°C) / (°F)
EDB : Entering dry bulb temp. (°C) / (°F)
TC : Total capacity (kW) / (kBtu/h)
SHC : Sensible heating capacity (kW) / (kBtu/h)
PI : Power input (kW)
