Names of Parts and Operations
Be sure to always holds the unit using the correct grip. (Injury may result from the unit falling)
Front
Operating/Indicator panel
Air outlet Louvre
(hand-operated)
Grip
(for carrying the unit)
Service cover
Odour sensor
Inside the air inlet (right side)
Temperature sensor,
Humidity sensor
Inside the air inlet (right side)
PM2.5 sensor
Inside the air inlet (right side)
Air inlets
Front/Side
Streamer unit
Inside the air inlet (left side)
Active Plasma Ion
generating unit
(inside the air outlet)
Wireless LAN connection
adaptor
For operating the air purifier via
smartphone (inside main unit)
Power supply plug
Power supply cord
Model name / Production no.
Back
