Daikin MC80ZBFVM3 - Specifications

Troubleshooting
38
English
Specifications
Model name MC80ZBFVM3
Power supply Single phase 50Hz 220-240V / 60Hz 220-230V
Operation mode
Air Purifying
Turbo Standard Low Quiet
Power consumption (W) 80 16 11 9
Operating sound (dB) 55 34 25 19
Airflow rate (m³/h) 480 210 132 84
Coverage area (m²) 62 *1
External dimensions (mm) 630(H) × 315(W) × 315(D)
Weight (kg) 9.8
Power supply cord length (m) 2.0
• These specification values are applicable to both 50Hz 220–240V and 60Hz 220–230V.
• Even when the power is off, approx. 1W (*2) of power is consumed to run the microcomputer.
• A-weighted emission sound pressure level is below 70 dB (A).
*1 Coverage area was calculated in accordance with JEM1467. (when FAN setting is Turbo)
*2 If the wireless LAN connection adaptor function is OFF.
