Daikin Modular T Smart ATB - Technical Data

10
Technical data
TECHNICAL DATA TABLE
SIZE
u.m.
03 04 05 06 07
Nominal air ow rate m
3
/h 800 1650 2300 2700 3900
Thermal eciency % 89 88 85 90 91
FLA A 1.7 3.4 4.6 5.2 7.9
FLI W 390 780 1060 1190 1820
Electrical connection V 230 V, 1 ph 230 V, 1 ph 230 V, 1 ph 230 V, 1 ph 230 V, 1 ph
WEIGHT TABLE
UNIT/SECTION
u.m.
ATB
03
ATB
04
05 06 07
ATB 15 ATB 25 ATB 16 ATB 26 ATB 36 ATB 17 ATB 27 ATB 37
Gross weight with
packaging
kg 210 260 140 280 150 270 110 190 330 130
Device weight kg 200 250 130 270 140 260 100 180 320 120
Filter weight kg 3 3 3 3 3 3 3 3 3 3
Fan weight kg 11 11 12 12 14 14 - 21 21 -
Heat recuperator
weight
kg 11 17 - 26 - 36 - - 46 -
