Daikin R32 Split Series Installer's Reference Guide

3 | Specific installer safety instructions
Installer reference guide
16
EKHWET90~120BAV3
R32 Split series – Domestic hot water tank
4P680077-1 – 2021.11
DANGER: RISK OF ELECTROCUTION
DANGER: RISK OF BURNING/SCALDING
Mounting the indoor unit (see
"7.3Mounting the indoor unit"[
4
37]
)
WARNING
Fixing method of the indoor unit MUST be in accordance with the instructions from
this manual. See "7.3Mounting the indoor unit"[437].
Piping installation (see
"8Piping installation"[
4
39]
)
WARNING
The field piping method MUST be in accordance with the instructions from this
manual. See "8Piping installation"[439].
DANGER: RISK OF BURNING/SCALDING
WARNING
Provide adequate measures to prevent that the unit can be used as a shelter by small
animals. Small animals that make contact with electrical parts can cause
malfunctions, smoke or fire.
WARNING
Some sections of the refrigerant circuit may be isolated from other sections caused
by components with specific functions (e.g. valves). The refrigerant circuit therefore
features additional service ports for vacuuming, pressure relief or pressurizing the
circuit.
In case it is required to perform brazing on the unit, ensure that there is no pressure
remaining inside the unit. Internal pressures need to be released with ALL the service
ports indicated on the figures below opened. The location is depending on model
type.
WARNING
▪ Only use R32 as refrigerant. Other substances may cause explosions and
accidents.
▪ R32 contains fluorinated greenhouse gases. Its global warming potential (GWP)
value is 675. Do NOT vent these gases into the atmosphere.
▪ When charging refrigerant, ALWAYS use protective gloves and safety glasses.
Electrical installation (see
"9Electrical installation"[
4
45]
)
DANGER: RISK OF ELECTROCUTION
