Daikin R32 Split Series Installer's Reference Guide

9 | Electrical installation
Installer reference guide
45
EKHWET90~120BAV3
R32 Split series – Domestic hot water tank
4P680077-1 – 2021.11
9 Electrical installation
In this chapter
9.1 About connecting the electrical wiring .................................................................................................................................. 45
9.1.1 Precautions when connecting the electrical wiring .............................................................................................. 45
9.1.2 Guidelines when connecting the electrical wiring ................................................................................................ 46
9.1.3 About electrical compliance .................................................................................................................................. 47
9.2 Connections to the indoor unit .............................................................................................................................................. 47
9.2.1 To connect the main power supply ....................................................................................................................... 47
9.2.2 To connect the booster heater power supply....................................................................................................... 48
9.2.3 To connect the WLAN cartridge (delivered as accessory)..................................................................................... 50
9.1 About connecting the electrical wiring
Typical workflow
Connecting the electrical wiring typically consists of the following stages:
▪ "9.2Connections to the indoor unit"[447]
9.1.1 Precautions when connecting the electrical wiring
DANGER: RISK OF ELECTROCUTION
WARNING
▪ All wiring MUST be performed by an authorised electrician and MUST comply
with the applicable legislation.
▪ Make electrical connections to the fixed wiring.
▪ All components procured on-site and all electrical construction MUST comply
with the applicable legislation.
WARNING
ALWAYS use multicore cable for power supply cables.
INFORMATION
Also read the precautions and requirements in the "2 General safety
precautions"[49].
