10 | Configuration
Installer reference guide
52
EKHWET90~120BAV3
R32 Split series – Domestic hot water tank
4P680077-1 – 2021.11
▪ Afterwards. If necessary, you can make changes to the configuration in the
menu structure or the overview settings.
INFORMATION
When the configuration wizard is finished, the user interface will show an overview
screen and request to confirm. When confirmed, the system will restart and the
home screen will be displayed.
Accessing settings – Legend for tables
You can access the installer settings using two different methods. However, NOT all
settings are accessible via both methods. If so, the corresponding table columns in
this chapter are set to N/A (not applicable).
Method Column in tables
Accessing settings via the breadcrumb in the home
menu screen or the menu structure. To enable
breadcrumbs, press the button in the home screen.
#
For example: [5.5]
Accessing settings via the code in the overview field
settings.
Code
For example: [6-0D]
See also:
▪ "To access the installer settings"[453]
▪ "10.8Menu structure: Overview installer settings"[492]
10.1.1 To access the most used commands
To change the user permission level
You can change the user permission level as follows:
1 Go to [B]: User profile.
2 Enter the applicable pin code for the user permission level. —
▪ Browse through the list of digits and change the selected digit.
▪ Move the cursor from left to right.
▪ Confirm the pin code and proceed.
Installer pin code
The Installer pin code is 5678. Additional menu items and installer settings are
now available.
Advanced user pin code
The Advanced user pin code is 1234. Additional menu items for the user are
now visible.
