EKHWET90~120BAV3
R32 Split series – Domestic hot water tank
4P680077-1 – 2021.11
1234
Advanced user
User pin code
The User pin code is 0000.
0000
User
To access the installer settings
1 Set the user permission level to Installer.
2 Go to [9]: Installer settings.
To modify an overview setting
Example: Modify [2‑02] from 23 to 3.
Most settings can be configured via the menu structure. If for any reason it is
required to change a setting using the overview settings, then the overview
settings can be accessed as follows:
1 Set the user permission level to Installer. See "To change
the user permission level"[452].
—
2 Go to [9.I]: Installer settings > Overview field
settings.
3 Turn the left dial to select the first part of the setting and
confirm by pressing the dial.
00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0
1
2
3
4 Turn the left dial to select the second part of the setting
00
01
23
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
2
5 Turn the right dial to modify the value from 23 to 3.
00
01
3
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
2
6 Press the left dial to confirm the new setting.
7 Press the center button to go back to the home screen.
