parTs lIsT
www.DaikinApplied.com 81 IM 919-3 • MICROTECH III CONTROLLER
parTs lIsT
Table 24: Parts List
Component Designation Description Daikin Part Number
MCB Main Control Board - MTIII 193407301
EXP A, B, C Expansion Module 193407501
ZNT1 Zone Temperature Sensor with Tenant Overide 113117701
ZNT1 Zone Temperature Sensor with Tenant Overide & Remote set point adjustment 113117801
DAT Discharge Air Temperature Sensor 193414602
EFT Entering Fan Air Temperature Sensor 193414602
OAT Outside Air Temperature Sensor 193414602
RAT Return Air Temperature Sensor 193414602
MAT Mixed Air Temperature Sensor 193414602
EWT Entering Water Temperature Sensor 193414602
ER EAT Energy Recovery Wheel Discharge Air Temperature Sensor 193414602
ER LAT Energy Recovery Wheel Exhaust Air Temperature Sensor 193414602
SPS1, 2 Duct Static Pressure Sensor 910117462
SPS3 Building Static Pressure Sensor 910117463
PSR1,2 Refrigerant Pressure Transducer Circuit 1 331764601
SHS1 Space Humidity Sensor, wall mount 067294901
SHS1 Space Humidity Sensor, duct mount 067295001
WFS Water Flow Switch 910103980
— MCB to EXP Direct Connector 193409701
— MCB to EXP Remote Connector 193409901
— MCB to Communication Module Connector 300047027
— Communication Module – LON-SCC 090016711
— Communication Module – LON-DAC 090016712
— Communication Module - BACnet MSTP 090016710
— Communication Module - BACnet IP 090016709
— Controller Terminal Block - 2 pole 193410302
— Controller Terminal Block - 3 pole 193410303
Controller Terminal Block - 5 pole 193410305
Controller Terminal Block - 6 pole 193410306
Controller Terminal Block - 7 pole 193410307
Controller Terminal Block - 8 pole 193410308
