Si181180
Outdoor Unit
Remo
val Pr
ocedu
re
7
6
Disconnect t
he 2
connector
s for t
he fan
motor [X106A] [
X107A].
7
Release the f
an motor
lead wir
es from the
hooks.
8
Release the l
ead wires
of t
he solenoid v
alves
and four way valve fr
om
the fi
xi
ng plate
and then
remove the el
ectr
ical
component assembly.
Step
Procedure
Points
(R12967)
[X106A]
[X107A]
(R9227)
(R9228)
8
10
Table of Contents
Default Chapter
3
Table of Contents
3
1 Outdoor Unit
4
Removal of Outer Panels
4
Removal of Pcbs / Electrical Components
7
Removal of Outdoor Fans / Fan Motors
14
Removal of Thermistors
16
Removal of Electronic Expansion Valves / Peripheral Equipments
17
Removal of Four Way Valve
21
Removal of Compressor
22
2 BP Unit
25
Removal of PCB Assembly
25
Removal of Electronic Expansion Valve Coils
28
