Tips for Servicing SiBE041401E
105 Trial Operation and Field Settings
Indoor Unit
Outdoor Unit: 20/25/35 class
Outdoor Unit: 50 class
Caution When pressing the button on the outdoor unit, do not touch the terminal board. It has a high
voltage and may cause electric shock.
(R19927)
Indoor unit ON/OFF button
Push here
Screwdriver
(R18256)
Terminal board
1
2
3
Screwdriver
(R20102)
Forced cooling operation
ON/OFF button (SW1)
Push
Terminal board
