Removal of Four Way Valve Si00-777
30 Removal Procedure
12.Removal of Four Way Valve
Procedure Warning Be sure to wait for 10 minutes or more after turning off all power
supplies before disassembling work.
Step Procedure Points
1
Remove the screw and
remove the four way
valve coil.
Preparation

Remove the sound blankets
according to "Removal of
Sound Blankets".
2
Pull out the electronic
expansion valve coil.
3
Remove the putty.
Four way valve coil
(R5885)
(R14026)
Electronic expansion
valve coil
Putty
(R5887)
