Si001169
Remova
l of Coils
/ Thermistors
Remo
val P
roced
ure
29
3
Remove the sound
blanket
(top upper)
.
4
Remove the disc
harge
pipe ther
mist
or.
5
At the back s
ide,
open
the out
door
temperatur
e thermi
stor
holder
.
Step
Proced
ure
Points
Sound blank
et
(top upper)
(R16920)
(R9635)
Discharge pipe thermistor
Outdoor temperature thermistor holder
(R9636)
30
32
