Removal of Coil
s / Therm
istors
Si001169
30
Removal Proc
edure
6
Release the out
door
temperatur
e thermi
stor
.
3.
Remove the four way
valve coil.
1
Remov
e t
he s
cr
ew.
2
Remove the four way
valve c
oil
.
Step
Proced
ure
Points
Outdoor temperature thermistor
(R9637)
(R9638)
Four w
a
y valv
e coil
(R9639)
31
33
