Daikin RYS50B2VMB - Remove Front Panel and Shield Plate

Si00-876 Removal of Outer Panels
Removal Procedure 3

The discharge grille has 4
hooks.
3
Remove the 6 screws
of the front panel.
4
Push the front panel
and lift the shield plate
to unfasten the hooks.
Step Procedure Points
(R2679)
Front panel
(R2680)
Shield plate
(R16560)
(1) Push the
front panel.
(2) Lift the shield
plate upwards.
