Daikin RYS50B2VMB - Remove Front Panel Side Hooks

Removal of Outer Panels Si00-876
4 Removal Procedure
5
Unfasten the left side
hooks, and then the
right side hook.
Remove the front panel.

Lift the front panel while
pushing the left side panel
inward.

Lift the front panel and
unfasten the right side hook.

When reassembling the
front panel, fit the right side
hook first.
Step Procedure Points
(R5249)
(R5250)
(R5251)
