Si00-876 Removal of Outer Panels
Removal Procedure 5
2. Remove the stop valve
cover.
1
Remove the screw of
the stop valve cover.
2
Pull the stop valve
cover downward to
unfasten the hooks and
remove it.

The stop valve cover has 6
hooks.
Step Procedure Points
Stop valve cover
(R5252)
(R16679)
(R16680)
