Si00-876 Removal of Outdoor Fan / Fan Motor
Removal Procedure 7
2. Remove the fan motor.
1
Disconnect the
connector for the fan
motor [S70].
2
The illustration shows
arrangement of the fan
motor lead wire.
Step Procedure Points
(R16431)
[S70]
(R2692)
Fan motor lead wire
(R2693)
