SiE12-411 Instruction
System Configuration 109
2. Instruction
Note: This instruction is appropriate for R22 models.
2.1 Contents and Reference Page
H
: Illustrations are for wall mounted type FTK(X)E25/35B as representative.
Model Series
Wall Mounted Type Duct Connected Type
Floor/Ceiling
Suspended Dual
Type
FTKE25/35BVM(A)
FTXE25/35BVMA
FTKD50/60/71BVM(A)
FTXD50/60/71BVMA
CDKD25~60CVM(A)
CDXD25~60CVMA
FLK25~60AVMA
FLX25~60AVMA
Read before Operation
Safety Precautions 110 110 110 110
Names of Parts 112 115 118 121
Preparation before Operation H 124 124 124 124
Operation
AUTO, DRY, COOL, HEAT, FAN
Operation H
127 127 127 127
Adjusting the Air Flow Direction 129 131 — 133
POWERFUL Operation H 135 135 135 135
OUTDOOR UNIT SILENT
Operation H
136 136 136 136
HOME LEAVE Operation H 137 137 137 137
INTELLIGENT EYE Operation 139 141 — —
TIMER Operation H 143 143 143 143
Note for Multi System 145 145 145 145
Care
Care and Cleaning 147 150 153 154
Trouble Shooting
Trouble Shooting 157 157 157 157
Drawing No. 3P098590-2H C : 3P098595-2M 3P132000-1B 3P077961-5E
