Instruction SiE12-411
150 System Configuration
FTK(X)D 50/60/71 B
CAUTION Before cleaning, be sure to stop the operation and turn the breaker OFF.
"
Indoor unit, Outdoor unit and Remote control
1. Wipe them with dry soft cloth.
"
Front grille
1. Open the front grille.
• Hold the grille by the tabs on the two sides and
lift it until it stops with a click.
2. Remove the front grille.
• Open the front panel further while sliding it to
either the left or right and pulling it toward you.
This will disconnect the rotation dowel on one
side. Then disconnect the rotation dowel on the
other side in the same manner.
3. Clean the front grille
• Wipe it with a soft cloth soaked in water.
• Only neutral detergent may be used.
• In case of washing the grille with water, dry it with cloth, dry it up in the shade after washing.
4. Attach the front grille
• Align the rotation dowels on the left and right of the front panel
with the slots, then push them all the way in.
• Close the front panel slowly. (Press the panel at both sides and
the center.)
CAUTION
Units
• Don’t touch the metal parts of the indoor unit. If you touch those parts, this may cause an injury.
• When removing or attaching the front grille, use a robust and stable stool and watch your steps
carefully.
• When removing or attaching the front grille, support the grille securely with hand to prevent it from
falling.
• For cleaning, do not use hot water above 40 °C, benzine, gasoline, thinner, nor other volatile oils,
polishing compound, scrubbing brushes, nor other hand stuff.
• After cleaning, make sure that the front grille is securely fixed.
To Next Page
