Specifications SiE12-411
22 Specifications
50Hz, 230V
Model FTKS20CVMB(9) FTKS25CVMB(9)(8)
Rated Capacity 2.0kW Class 2.5kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.7 (272) 7.7 (272)
M 5.9 (208) 5.9 (208)
L 4.2 (148) 4.2 (148)
SL 3.6 (127) 3.6 (127)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimensions (W×D×H) mm 834×325×258 834×325×258
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/32/25/22
Sound Power H dBA 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm
φ18.0 φ18.0
Drawing No. 3D044242B 3D044243B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model FTKS35CVMB(9)(8) FTKS50BVMB
Rated Capacity 3.5kW Class 5.0kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.7 (272) 11.4 (402)
M 6.0 (212) 9.7 (342)
L 4.4 (155) 8.0 (282)
SL 3.8 (134) 7.1 (251)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 40
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 290×795×238
Packaged Dimensions (W×D×H) mm 834×325×258 840×338×280
Weight kg 7.5 9
Gross Weight kg 11 13
Operation
Sound
H/M/L/SL dBA 39/33/26/23 44/40/35/32
Sound Power H dBA 57 63
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ12.7
Drain mm
φ18.0 φ18.0
Drawing No. 3D044244B 3D040781A
