Specifications SiBE18-821_C
14 Specifications
50 Hz, 220 - 230 - 240 V
Model
CTXG50EV1BW CTXG50EV1BS
Cooling Heating Cooling Heating
Rated Capacity 5.0 kW Class 5.0 kW Class
Front Panel Color Mat Crystal White Mat Crystal Silver
Airflow Rates
m³/min
(cfm)
H 11.3 (398) 12.6 (444) 11.3 (398) 12.6 (444)
M 9.1 (320) 10.6 (373) 9.1 (320) 10.6 (373)
L 7.1 (250) 8.7 (306) 7.1 (250) 8.7 (306)
SL 6.7 (236) 7.7 (271) 6.7 (236) 7.7 (271)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.15 - 0.14 - 0.13 0.15 - 0.14 - 0.13 0.15 - 0.14 - 0.13 0.15 - 0.14 - 0.13
Power Consumption (Rated) W 30 30 30 30
Power Factor (Rated) % 90.9 - 93.2 - 96.2 90.9 - 93.2 - 96.2 90.9 - 93.2 - 96.2 90.9 - 93.2 - 96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 275 × 840 × 150 275 × 840 × 150
Packaged Dimensions (H × W × D) mm 222 × 894 × 345 222 × 894 × 345
Weight (Mass) kg 9 9
Gross Weight (Gross Mass) kg 13 13
Operation
Sound
H / M / L / SL dBA 47 / 41 / 35 / 32 47 / 41 / 35 / 32 47 / 41 / 35 / 32 47 / 41 / 35 / 32
Sound Power dBA 64 64 64 64
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D051105 3D051106
Model
FTXG25JV1BW FTXG25JV1BS
Cooling Heating Cooling Heating
Rated Capacity 2.5 kW Class 2.5 kW Class
Front Panel Color White Silver
Airflow Rates
m³/min
(cfm)
H 8.8 (311) 9.6 (339) 8.8 (311) 9.6 (339)
M 6.8 (240) 7.9 (279) 6.8 (240) 7.9 (279)
L 4.7 (166) 6.2 (219) 4.7 (166) 6.2 (219)
SL 3.8 (134) 5.4 (191) 3.8 (134) 5.4 (191)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 29 29
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.12 - 0.11 - 0.11 0.09 - 0.08 - 0.08 0.12 - 0.11 - 0.11
Power Consumption (Rated) W 18 - 18 - 18 24 - 24 - 24 18 - 18 - 18 24 - 24 - 24
Power Factor (Rated) % 90.9 - 97.8 - 93.8 90.9 - 94.9 - 90.9 90.9 - 97.8 - 93.8 90.9 - 94.9 - 90.9
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 915 × 155 295 × 915 × 155
Packaged Dimensions (H × W × D) mm 285 × 1,003 × 377 285 × 1,003 × 377
Weight (Mass) kg 11 11
Gross Weight (Gross Mass) kg 15 16
Operation
Sound
H / M / L / SL dBA 38 / 32 / 25 / 22 39 / 34 / 28 / 25 38 / 32 / 25 / 22 39 / 34 / 28 / 25
Sound Power dBA 54 55 54 55
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
16.0 or
φ
18.0
φ
16.0 or
φ
18.0
Drawing No. 3D066165A 3D066436A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
