4. Remote Controller
4.1 Wired Remote Controller
4.1.1 BRC1D528
Connectors and
Other Parts
PCB Detail
1) P1, P2 Terminal for indoor unit
2) R1T Room temperature thermistor
3) SS1 MAIN / SUB setting switch
∗
Refer to page 162 for detail.
R1T
P2
P1
SS1
2P113638-2
