SA Indoor Unit - FFQ, FCQ, FDBQ, FBQ, FHQ Series SiBE18-821_C
286 Operation Manual
English 29
3
Up/down direction
Left/right direction
Position 0 ,
Position 1 ,
Position 2 ,
Position 3 , and
Position 4 .
4
Up/down direction
Left/right direction
•
Pressing buttons changes the
setting to (in order) ,
•
Selecting will cause
the airflow direction blades to
swing back and forth.
For the swing setting only, all
positions will be displayed.
•
When you select one of positions 0
to 4, the airflow direction blades
stay in a fixed position.
* The illustration is a display when position 2
is selected.
•
Press buttons to select the
desired airflow direction.
Press Menu/Enter button to return
to the basic screen.
To Next Page
