SiBE18-821_C Outdoor Unit

Removal Procedure 435

8 Unfasten the 3 hooks

with a flat screwdriver

and remove the suction

grille.

9 Pull the outdoor

temperature thermistor

and slide it to the right.

Detach the outdoor

temperature thermistor.

Step

Procedure Points

Suction

grille

(R12964)

(R12965)

(R9218)

Outdoor

temperature

thermistor
