Daikin Super Multi Plus E-Series RMXS112E8V1B - 1. Outdoor Unit

SiBE18-821_C Specifications
Specifications 15
50 Hz, 220 - 230 - 240 V
Model
FTXG35JV1BW FTXG35JV1BS
Cooling Heating Cooling Heating
Rated Capacity 3.5 kW Class 3.5 kW Class
Front Panel Color White Silver
Airflow Rates
m³/min
(cfm)
H 10.1 (357) 10.8 (381) 10.1 (357) 10.8 (381)
M 7.3 (258) 8.6 (304) 7.3 (258) 8.6 (304)
L 4.6 (162) 6.4 (226) 4.6 (162) 6.4 (226)
SL 3.9 (138) 5.6 (198) 3.9 (138) 5.6 (198)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 29 29
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.13 - 0.12 - 0.12 0.16 - 0.15 - 0.14 0.13 - 0.12 - 0.12 0.16 - 0.15 - 0.14
Power Consumption (Rated) W 26 - 26 - 26 32 - 32 - 32 26 - 26 - 26 32 - 32 - 32
Power Factor (Rated) % 90.9 - 94.2 - 90.3 90.9 - 92.8 - 95.2 90.9 - 94.2 - 90.3 90.9 - 92.8 - 95.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 915 × 155 295 × 915 × 155
Packaged Dimensions (H × W × D) mm 285 × 1,003 × 377 285 × 1,003 × 377
Weight (Mass) kg 11 11
Gross Weight (Gross Mass) kg 15 16
Operation
Sound
H / M / L / SL dBA 42 / 34 / 26 / 23 42 / 36 / 29 / 26 42 / 34 / 26 / 23 42 / 36 / 29 / 26
Sound Power dBA 58 58 58 58
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
16.0 or
φ
18.0
φ
16.0 or
φ
18.0
Drawing No. 3D066437A 3D066438A
Model
CTXG50JV1BW CTXG50JV1BS
Cooling Heating Cooling Heating
Rated Capacity 5.0 kW Class 5.0 kW Class
Front Panel Color White White
Airflow Rates
m³/min
(cfm)
H 10.5 (371) 11.4 (402) 10.5 (371) 11.4 (402)
M 8.7 (307) 9.8 (346) 8.7 (307) 9.8 (346)
L 6.9 (244) 8.1 (286) 6.9 (244) 8.1 (286)
SL 5.9 (208) 7.1 (251) 5.9 (208) 7.1 (251)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 29 29
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.16 - 0.15 - 0.14 0.19 - 0.18 - 0.17 0.16 - 0.15 - 0.14 0.19 - 0.18 - 0.17
Power Consumption (Rated) W 32 - 32 - 32 38 - 38 - 38 32 - 32 - 32 38 - 38 - 38
Power Factor (Rated) % 90.9 - 92.8 - 95.2 90.9 - 91.8 - 93.1 90.9 - 92.8 - 95.2 90.9 - 91.8 - 93.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 915 × 155 295 × 915 × 155
Packaged Dimensions (H × W × D) mm 285 × 1,003 × 377 285 × 1,003 × 377
Weight (Mass) kg 11 11
Gross Weight (Gross Mass) kg 15 15
Operation
Sound
H / M / L / SL dBA 44 / 41 / 35 / 32 44 / 41 / 35 / 32 44 / 41 / 35 / 32 44 / 41 / 35 / 32
Sound Power dBA 60 60 60 60
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
16.0 or
φ
18.0
φ
16.0 or
φ
18.0
Drawing No. 3D066439B 3D066440B
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
