Mode Indicators
Selects the operational mode of the equipment.
HEAT - Indicates the heating mode.
COOL - Indicates the air conditioning mode.
HEAT & COOL - Indicates the system will automatically change-
over between heat and cool modes as the temperature varies.
OFF - Indicates heating and cooling is turned off.
Room Temperature Display
Indicates the current room temperature and displays the outdoor
temperature when selected.
The scrolling display will be used to help you easily navigate the setup
screens in the thermostat.
Get to Know Your Thermostat
Outdoor icon
Indicates the temperature displayed is from the optional outdoor
sensor.
Outdoor
Fan On
AUXHEAT
Setup Step
2nd
Stage
COOL
88
88
Lo
88
H
88
Display Features
