Outdoor
Fan On
AUXHEAT
Setup Step
2nd
Stage
COOL
88
88
Lo
88
H
88
PAGE 3
Desired Set Temperature
Indicates desired room temperature(s).
Setup Step icon
Indicates the step number when the thermostat is in the
setup mode.
icon
Indicates the keypad has been locked.
2nd Stage icon
Indicates what stage of cooling or heating is currently energized.
Get to Know Your Thermostat
Display Features
6
6
