SiUS331604E Outline of Control (Indoor Unit)
Functions and Control 58
6.4 Operations of Swing Flaps
Note: ∗1.L or LL on FXFQ models only
Fan
Flap
FXFQ FXHQ FXAQ
Heating
Hot start from defrosting
operation
Swing OFF Horizontal Horizontal Horizontal
Airflow direction set OFF Horizontal Horizontal Horizontal
Defrosting operation
Swing OFF Horizontal Horizontal Horizontal
Airflow direction set OFF Horizontal Horizontal Horizontal
Thermostat OFF
Swing LL Horizontal Horizontal Horizontal
Airflow direction set LL Horizontal Horizontal Horizontal
Hot start from thermostat
OFF mode (for prevention
of cold air)
Swing LL Horizontal Horizontal Horizontal
Airflow direction set LL Horizontal Horizontal Horizontal
Stop
Swing OFF Horizontal Horizontal Totally closed
Airflow direction set OFF Horizontal Horizontal Totally closed
Cooling
Thermostat ON in
program dry
Swing L (∗1) Swing Swing Swing
Airflow direction set L (∗1) Set Set Set
Thermostat OFF in
program dry
Swing
OFF or L
Swing Swing Swing
Airflow direction set Horizontal or Set Set Set
Thermostat OFF in
cooling
Swing Set Swing Swing Swing
Airflow direction set Set Set Set Set
Stop
Swing OFF Horizontal Horizontal Totally closed
Airflow direction set OFF Horizontal Horizontal Totally closed
Micro-computer control
(including cooling
operation)
Swing L Swing Swing Swing
Airflow direction set L Set Set Set
