SINGLE SCREW CHILLERS IMM
Engineered for Flexibility and Performance 7
compressor
starter cabinet
Evaporator
condenser
Flash-tank Economizer
A View
condenser inlet
condenser outlet
evaporator inlet
evaporator outlet
control cabinet
screen
Fig.2-4
