SINGLE SCREW CHILLERS IMM
Engineered for Flexibility and Performance 3
1. Nomenclature
1.1 Water Cooled Single Screw Chiller (Flooded)
1.2 Water Cooled Single Screw Chiller (Falling-film)
Compressor Code
Condenser Code
Evaporator Code
Power Supply:
F:380V/50Hz
Water Cooled Single Screw Chiller
Application Code
Starting Method:
Y:Star-detla V:Variable frequency
Condenser Pass:2-pass
Condenser Tube Type Code
Evaporator Pass：3-pass
Evaporator Tube Type Code
1.3 Water Cooled Single Screw Chiller (New Platform for ZUW-HCA)
Compressor code
Refrigerant circuits
Economizer Code:
H:Vertical N:None
Water Cooled Single Screw Chiller
Power Supply:
F:380V/50Hz
G:400V/50Hz
K:415V/50Hz
Design Code
Refrigerant Code:
C:R134a A:R410A
Running Frequency Code:
A:60Hz B:55Hz C:50Hz D:45Hz
ZUWY:Null value
Application Code:
N:Normal B:Hot gas bypass
Evaporator Type:
F:Falling film E:Flooded
Number of Evaporator tubes
Evaporator Tube Type
Evaporator Pass Code
Starting method:
Y:Star-delta V:Variable frequency
Evaporator Code:
Diameter:30 inch,Length:9 feet
Condenser Type:
C:Shell&tube
N:Shell&tube with built-in oil
separator
Condenser Code:
Diameter:22 inch,Length:9 feet
Condenser Tube Type
Number of Condenser tubes
Condenser Pass Code
