4/29/03
Manual V-16, V-24, VH-24, V-40 & VH-40 4 – Section I
SPECIFICATIONS
Model Number: V-16 V-24/VH-24 V-40/VH-40
Capacity:
Throat Inches 16 23-1/2 41
Work Height Inches 11 12-1/2 12-1/2
Table:
Work Table Inches 23-1/2 x 23-1/2 26-3/8 x 26-3/8 26-3/8 x 26-3/8
Auxiliary Inches -- 9 x 22-3/8 15-1/2 x 21-1/2
Height from Floor Inches 38 42 41
Travel-Manual or Hydraulic Inches -- 10 10
Tilt-Left Degree 10 10 10
Tilt-Right Degree 30 30 30
Table Weight Capacity Lbs. 850 850 850
Blade:
Width Minimum Inches 1/8 1/8 1/8
Width Maximum Inches 5/8 1 3/4
Length Minimum/Maximum Inches 128/133 178/187 134/140 (2
wheels)
Length Minimum/Maximum Inches -- -- 186/189 (3
wheels)
Wheel Diameter Inches 16-1/2 24-1/2 16-1/2
Band Speed:
Low Range FPM 60 to 590 50 to 425 50 to 425
High Range FPM -- 425 to 4250 425 to 4250
Drive Motor HP 1 2.2 2.2
Welder Capacity:
Inches 1/8 – 5/8 1/8 – 1 1/8 – 1
VH models equipped
with hydraulic table
Hydraulic Motor:
HP -- 1/3 1/3
Height of Machine:
Inches 72 90 78
Floor Space:
Inches 38 x 25 60 x 60 72 x 60
Shipping Weight:
Manual Table Lbs. 1000 2025 2025
Hydraulic Table Lbs. -- 2225 2395
